Wing Solar
Wing Solar
| Section mm² | Insulation thickness (mm) | Approx. outside diameter (mm) | Reference weight (kg/km) | Max resistance at 20 ºC (Ω/km) |
|---|---|---|---|---|
| 1.5 | 0.7 | 4.5 | 27 | 19.9 |
| 2.5 | 0.7 | 5.0 | 34 | 11.9 |
| 4 | 0.7 | 6.0 | 42 | 7.45 |
| 6 | 0.7 | 6.2 | 52 | 4.96 |
| 10 | 0.8 | 8.3 | 87 | 2.98 |
| 16 | 0.8 | 9.4 | 112 | 1.86 |
| 25 | 1.0 | 11.7 | 172 | 1.19 |
| 35 | 1.0 | 13.6 | 220 | 0.827 |
| 50 | 1.2 | 16.0 | 310 | 0.579 |
| 70 | 1.2 | 18.1 | 413 | 0.413 |
| 95 | 1.4 | 20.4 | 542 | 0.331 |
| 120 | 1.4 | 22.3 | 644 | 0.248 |
| 150 | 1.6 | 25.5 | 730 | 0.199 |
| 185 | 1.6 | 28.0 | 895 | 0.156 |
| 240 | 1.8 | 31.7 | 1015 | 0.124 |
