Best Quality 24V 48V 96V 30A 40A 60A 80W 100A MPPT Charge Controller Charger Solar Panel MPPT

1 / 5

Best Quality 24V 48V 96V 30A 40A 60A 80W 100A MPPT Charge Controller Charger Solar Panel MPPT

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

📊

Basic Information

Model NO.:LCS-MT01

Certification:ISO, CE

Application:Collector Controller, Solar System Controller, Voltage Controller

Rated Voltage:12V

Origin:China

HS Code:9032899099

Production Capacity:50000PCS/Month

📦

Packaging & Delivery

Package Size:50.00cm * 40.00cm * 40.00cm

Gross Weight:12.000kg

Transport Package:Carton

⚙️

Product Parameters

MODEL	LCS-30415	LCS-40415	LCS-60415	LCS-80415	LCS-100415
System Voltage	12v/24v/36v/48v/96v
Max.Solar Input Voltage	150V(25ºC) 138V(-25ºC)			250V(25ºC) 225V(-25ºC)
Battery Type	Lithium battery, Lead acid battery
Rated Charging Current	30A	40A	60A	80A	100A
Max PV Input Power (12V)	390W	540W	800W	1040W	1300W
Conversion Efficiency	≤98%
MPPT Tracking Efficiency	>99%
Waterproof Level	IP32

✨

Key Features

High efficiency MPPT control algorithm, MPPT efficiency ≥99.5%.
Three-stage charging mode: Fast, Constant, and Floating charge to prolong battery life.
Multiple discharge modes: ON/OFF, PV voltage control, and Dual Time control.
Supports various battery types: Flooded, Sealed lead acid, Gel, and user-defined batteries.
Comprehensive LCD display: PV input voltage, current, energy generated, and battery status.
RS485 communication support for easy system integration management.
Certified quality: CE, RoHS, and FCC approved.

📷

Detailed Photos

🏢

Production Overview

❓

Frequently Asked Questions

What is the maximum tracking efficiency of this MPPT controller?

The controller utilizes a high-efficiency MPPT algorithm providing a tracking efficiency of ≥99.5% and a conversion efficiency of up to 98%.

Which battery types are compatible with this device?

It supports Sealed lead-acid, Gel, and Flooded batteries, as well as Lithium batteries. Other specific battery types can also be user-defined.

Can I monitor the system performance in real-time?

Yes, the built-in LCD screen provides comprehensive information including PV input voltage, charging current, generated energy, and system status. It also supports RS485 communication for remote management.

What are the different charging stages?

The controller operates in three stages: fast charge, constant charge, and floating charge. This process helps activate battery performance and extends its service life.

What is the waterproof rating of the controller?

This series of MPPT charge controllers is rated at IP32, providing protection against solid objects and light water spray.

Does the controller support high-voltage solar inputs?

Yes, depending on the specific model, the maximum solar input voltage can reach up to 150V or 250V, making it suitable for various solar panel configurations.

Best Quality 24V 48V 96V 30A 40A 60A 80W 100A MPPT Charge Controller Charger Solar Panel MPPT

Product Description

Basic Information

Packaging & Delivery

Product Parameters

Key Features

Detailed Photos

Production Overview

Frequently Asked Questions
